Customizable 45T Plastic Fan Injection Molding Machine Vertical

Name: Customizable 45T Plastic Fan Injection Molding Machine Vertical
Brand: JINTONG injection machine
Price: 12 USD

Wholesale Customizable 45T Plastic Fan Injection Molding Machine Vertical from china suppliers

Place of Origin : Guangdong, China

Model Number : JTT-450D

Brand Name : JINTONG injection machine

Packaging Details : plywood for plastic fan injection molding machine 45T

Supply Ability : 60 Piece/Pieces per Month plastic fan injection molding machine 45

Price : $12,000.00 - $14,000.00/pieces

Plastic Processed : ABS

Condition : New

Style : VERTICAL

Plasticizing Capacity(g/s) : 80

Mold Height(mm) : 85 - 310 mm

Ejector Number : 1

Ejector Stroke(mm) : 45 mm

Ejector Force(kN) : 13 kN

Theoretical Shot Volume(cm³) : 115 cm³

Injection Rate (g/s) : 71 g/s

Machine Type : Hydraulic

Injection Weight (g) : 105 g

Screw Speed (rpm) : 1 - 205 rpm

Screw diameter (mm) : 35 mm

Screw L/D Ratio : 25

Distance between Tie Bars : 410mm

Weight (KG) : 2000 kg

Type : Other

Open Stroke(mm) : 350 mm

Power (kW) : 9 kW

Warranty : 1 Year

Key Selling Points : Competitive Price

Applicable Industries : Manufacturing Plant

Showroom Location : None

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Motor, Pump, PLC, Pressure vessel

product name : plastic injection molding machine 45T

screw diameter : 30 35

machine color : grey blue yellow green

After-sales Service Provided : Online support

After Warranty Service : Video technical support

Marketing Type : Ordinary Product

Port : Shenzhen

Contact Now

Customizable 45T Plastic Fan Injection Molding Machine For Your Production Needs

Product Description

plastic fan injection molding machine 45T JTT-450D

Clamping Force: 45T

Injection Weight: 54-105g

Vertical clamping, vertical injection
D-single slide table(one up die and one low die)
Single slide table offer operation convenience
Optional saving energy motor
Fixed low die and movable up die to avoid insert part shift; oil hydraulic unit under low die to ejector finshed products; ejector speed and stroke adjusted by actual demand
Combined with conveyor system used on production line

Customizable 45T Plastic Fan Injection Molding Machine Vertical

Main Features

With lower mold can slid out towards operation direction, inserts, placed parts and finished products are all finished outside the clamping unit. It works safely and suits for those inserts that are hard to place.

Suitable for all kinds of insert molding.

Nitrided steel screw and barrel, directly driven by high torque motor, with multi stages injection pressure, better plasticization.

Vertical compression clamping system, closing mold with high speed lower pressure as well as multi pressure control and prolong mold using life.

Electric protection device can not happen wrong action and maintain the operators safety.

Auto life injection base, it is easy for replacement of material and mold.

Certifications

Detailed Images

Our Service

PRODUCT ADVANTAGE

Energy-saving: save 30% energy compared to similar products by using SIFU pump system

High efficiency: SIFU motor have max speed 2200/min to increase oil pump output and improve more than 15% productivity speed

Low heating: save 55% cooling water quantity at least compared to similar products

Low noise: optimize motor working condition with imported bearing and oil pump to reduce 15-20db working noise

Precision: use completely close-cycle control with pressure sensor and motor rotary encoder to improve product consistency

SERVICE ADVANTAGE

17 years of customer service experience and summarizing customer feedback, Jintong develop a systematic and standardized service process, and also establish 24 hour response mechanism to wensure timely solve customers problems and offer perfect service to customers as soon as possible.
